MSL.NC Vertical Sterilizer

CSSD Solutions

The MSL.NC series vertical Class N pressure steam sterilizer offers comprehensive sterilization capabilities, accommodating instruments, textiles, glassware, mediums, rubber, liquids, and wastes with ease.

WGWT-001-001

MSL.NC Vertical Steam Sterilizer

The MSL.NC series vertical Class N pressure steam sterilizer offers comprehensive sterilization capabilities, accommodating instruments, textiles, glassware, mediums, rubber, liquids, and wastes with ease.

Its versatility makes it indispensable in biomedical research institutions, laboratories, and medical health centers, ensuring the highest standards of sterilization across a wide range of applications.

Overview

The MSL.NC series vertical Class N pressure steam sterilizer offers comprehensive sterilization capabilities, accommodating instruments, textiles, glassware, mediums, rubber, liquids, and wastes with ease.

Its versatility makes it indispensable in biomedical research institutions, laboratories, and medical health centers, ensuring the highest standards of sterilization across a wide range of applications.

Specifications
Specification
ModelChamber VolumeNet WeightChamber (mm) Dimension(φ*L)Overall (mm) Dimension(W*H*D)Power Supply
MSL.NC50L50L70Kg316*667476*616*9903KW, AC220V/110V, single phase
MSL.NC80L80L94Kg386*695546*688*10304.5KW, AC220V/110V, single phase
MSL.NC100L100L102Kg386*895546*688*12205.4KW, AC220V/110V, single phase
MSL.NC120L120L178Kg500*620700*850*10208.0KW, AC380V/220V, three phase
MSL.NC150L150L198Kg500*780700*850*11809.3KW, AC380V/220V, three phase
Features
Features
  • Microcomputer control system, touch screen displaying
  • Positive pressure pulse exhaust function for solid program
  • Built-in water tank, automatic sterilization process
  • Automatic control function of fast exhaust and slow exhaust avoids liquid overflow
  • Electricity black-out holding function
  • Internal printer
  • Sterilization temperature range: 105℃~138℃
  • Dissolution temperature: 40℃~100℃
  • Holding temperature: 40℃~60℃
  • Dissolution time: 0~72 hours
  • Holding time: 0~72 hours
  • Chamber material:  Stainless steel
  • Accessory: Stainless steel sterilizing basket
